GT 300 GPS Personal tracker
Download PDF
Description
Feature Products
Track protocol,server through GPRS/GSM network,Lower power and scheduled GPS position
Product Description
GT300 is a powerful GPS phone for personal tracking. With superior receiving sensitivity, fast TTFF and GSM frequencies 850/900/1800/1900. Its location can be real time or schedule tracked by backend server or specified terminals. Base on the embedded @Track protocol the GT300 can communicate with the backend server through GPRS/GSM network, transfer reports of Emergency ,Geo-fencing, Lower power and scheduled GPS position etc User can easy to dial the preset phone number by the four quick dial buttons and SOS button. Service provider can easy to setup their tracking platform base on the functional @Track protocol.
Specification
|
Weight |
54g |
|
Dimensions |
73.0（L）× 45.0（W）
× 15.8（H）mm |
|
Operating
temperature |
-20℃- 80℃ |
|
Operating
humidity |
5% - 95% |
|
LED
indicator |
Three LED indicators: GPS-
Blue; GSM- Green; Power- Red |
|
Keypad
indicator |
SOS, Mode, Up, Down,
ON/OFF |
|
Key for emergency
call |
SOS |
|
GSM |
850/ 900/ 1800/ 1900 MHz |
|
GPRS |
Class12, TCP/ IP built-in GSM
Module |
|
GPS |
MT3336 |
|
GPS
Channels |
22 |
|
Tracking
sensitivity |
-165dBm |
|
Acquisition
sensitivity |
-148dBm |
|
Locating time
cost |
Hot start: <2 sec（open sky）
|
|
Warm start: <15 sec |
|
Cold start: <38 sec（open
sky） |
|
Antenna |
Built-in GSM quad band
antenna, GPS high gain antenna |
|
Battery |
3.7VDC/1100mAh |
|
Standby
time |
98hours |
|
Call
time |
5.5hours |
Features
- GPS real time tracking
- Support TCP/UDP modes
-
GT 300 MHz Quad-band
-
GPS / GSM / GPRS wireless network
-
Suitable for cargo, container and personal
tracking
-
3 optional mode: Arm, Disarm and Send location
to platform by adjustable time
-
1100mAh large capacity internal battery for long
working time
-
Voice Monitor function
-
Phone call avaliable - 2 family numbers
supported
-
SOS emergency alarm
-
Geo-fence alarming function
-
Web-based online tracking platform
|
|
